Modern Industrial and Commercial LED Flood Light

This is a industrial grade, high-performance modern LED flood light, made of die-cast aluminum, with ultra-thin and robust structure, providing a larger heat dissipation area. It boasts IP66 and 10KV surge protection, making it ideal for any outdoor environment, including garden, sports venues, parking lots, intersections and area lighting. Its simplified wiring and flexible adjustable U-shaped bracket make it easier to install. Multiple symmetrical beam angles are available to illuminate areas of different shapes, with excellent uniformity and glare control.

Product Features

36W, 50W, 70W, 100W, 120W, 150W, 180W, 200W, 250W, 300W
IP66 and 10KV surge protection
Equip with vent to avoid internal fogging and frosting
Six beam angles and 0-10V dimming

🔔 Ledrhythm products are designed for the global market. Please contact our sales team for certification details.

🔔 Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.

Series	SlimⅡ
Power	36W, 50W, 70W, 100W, 120W, 150W, 180W, 200W, 250W, 300W
Expected Life	Over 50,000 hrs
Rating	IP66
Color Rendering Index (CRI)	>70
Operating Temp	-30°C – +45°C
Relative Humidity	0-90% RH
Power Factor	≥95%
Input Line Voltage	120-277/277-480 VAC
Input Line Frequency	50/60 Hz
LED Chips	OSRAM
DIMMING	0-10V Optional
LED Efficiency	130 lm/W, 150 lm/W
Warranty	5-Year
Housing	Die Cast Aluminum ADC12
Gasketing	Neoprene Rubber
Finish	Protective UV Stabilized Powdercoat 4000 Hour Salt Spray Tested to ASTM B117
Application	Parking lot, stadium, area, garden, billboard, crossroads

modern LED flood lighting

What is the function of 10V surge protection?

The main function of 10V surge protection is to prevent sudden voltage fluctuations from damaging the internal power supply and driver module of the fixture. This will accelerate the aging of the LED driver and shorten the life of the fixtures.

Resists tiny transient surges on the power grid, preventing fatigue in driver electronics caused by repeated surges.
Extends the life of LED drivers and maintains stable light output.
Enhances the reliability of outdoor flood lighting, ensuring safe operation in unstable voltage environments such as factories, ports and sports fields.

Can you design lighting for my outdoor environment?

Yes, we offer free custom outdoor flood lighting services. Simply provide site dimensions and intended use (parking lot, sports, building facade). We will perform professional optical simulations (Dialux/Relux) based on your specific project requirements and output the following information for your reference:
