Modular Sports LED Flood Light With Lens

“Galileo” is one of our best LED flood lighting. Each module is 300W, supports up to three modules 900W, and features large area aluminum heatsink on the back for independent cooling. Two light distribution methods are available: reflector cup and precision lens. The lens offers different beam angles and excellent glare control. Its design aims to provide more uniform ground illuminance, softer visual experience, and less glare. Adjustable mounting bracket allows for greater installation flexibility. It can meet most indoor or outdoor sports lighting standards.

Product Features

300W, 600W, 900W
Beam Angle: 24°, 40°, 60°, Asymmetric 50°
IP66, all aluminum material
Precise light distribution & excellent glare control
Supports training, competition, and cleaning modes
Intelligent control system, zoned dimming

🔔 Ledrhythm products are designed for the global market. Please contact our sales team for certification details.

🔔 Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.

The biggest advantage of this LED flood light is its light control, extremely low glare and no spillover light. Therefore, its undoubtedly professional choice for sports lighting such as tennis, badminton, pickleball and basketball, whether indoors or outdoors.

High-power and modular design, one module is 300W, and can be made into three modules.
Precise light control: Light is even and does not spill over, reducing glare and enhancing softness.
Professional protection: IP66 protection level, able to operate for a long time in high humidity and strong condensation environment.
Efficient heat dissipation: Adopting Aluminum Profile, combined with innovative design, it has excellent corrosion resistance and heat dissipation performance.
Can be combined with an intelligent control system to provide zone dimming, adapt to multiple scene modes (such as training, competition or cleaning mode) to further optimize energy management.

Series	Galileo
Power	300W, 600W, 900W
Expected Life	Over 50,000 hrs
Rating	IP66
Color Rendering Index (CRI)	>70
Operating Temp	-30°C – +45°C
Relative Humidity	0-90% RH
Power Factor	≥95%
Input Line Voltage	120-277/277-480 VAC
Input Line Frequency	50/60 Hz
LED Chips	OSRAM
DIMMING	0-10V Optional
LED Efficiency	3000K-120 lm/w、4000K-130 lm/w、5000K-130 lm/w、5700K-130 lm/w
Warranty	5-Year
Housing	Aluminum Profile
Lens	PC/ADC12
Finish	Protective UV Stabilized Powdercoat 4000 Hour Salt Spray Tested to ASTM B117
Application	Professional tennis courts, pickleball courts, basketball courts

led indoor smart flood light optics

How important is the light distribution in LED flood lights for sports?

Precise and professional light distribution enhances sports safety and efficiency, offering both bright and comfortable vision. LED flood lights through different lenses and installation angles, can maintain uniform brightness in the desired area, eliminating dark zones and shadows, and effectively reducing glare. During rapid movement, details remain clearly visible without being dazzling.

What are modular LED lighting?

Modular LED lights consist of multiple module light sources with the same power. Each module contains independent LED and lens, offering better heat dissipation efficiency and allowing for individual adjustment, replacement, and maintenance. It is very common in high-power LED lighting.

Can LED flood lights operate stably even when exposed to the outdoors year-round?

With IP66 waterproof and dustproof rating and corrosion-resistant housing, it can perfectly protect the internal components of the fixture and can operate outdoors for long time without maintenance under normal circumstances.

How should I choose the wattage for this LED flood light?

This depends on the illuminance requirements of different sports fields. The higher the installation height or the brighter the desired brightness, the higher the wattage needs to be. For simple recreational sport venues, 300W is sufficient, 600W is recommended for higher illuminance, and 900W is recommended for professional competition venues.
