65℃ High Temperature LED Flood Light

This high temperature LED flood light are upgrade from standard ‘SlimⅢ’ flood light. Its housing is made of die-cast aluminum with larger heat sink, combined with more heat resistant driver power, and separates the driver from light body, ensuring stable operation in ambient temperatures up to 65°C. Unlike high temp high bay lights, this fixture with IP66/IK08 and flexible mounting bracket makes it suitable not only for indoor use but also for harsh outdoor heat applications. 120° beam angle provides wider and more uniform light coverage. Supports 0-10V dimming for further improved energy efficiency.

Product Features

80W,100W,120W,150W,200W
Luminous efficiency 150lm/W+
Withstands ambient temperature of 65℃
Excellent heat resistance and heat dissipation performance
IP66 waterproof & 10KV surge protection
0-10V dimming optional

🔔 Ledrhythm products are designed for the global market. Please contact our sales team for certification details.

🔔 Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.

65℃ high temperature LED flood light

“SlimⅢ Pro” high temp LED flood light can be matched with reflector cups of various angles, which can make the lighting of various scenes more scientific, more standardized and more energy-saving. The reflector cup adopts a vacuum coating process, which makes the surface have many superior properties such as wear resistance, heat resistance, corrosion resistance, oxidation resistance and decoration, which are superior to the solid material itself.

Common Applications of SlimⅢ Pro in High Temp Industrial Areas

Flood lighting in refineries、glass Factory、casting zones.
Illuminate conveyor belts, cooling systems, and kiln zones.
Outdoor sports stadiums in hot weather
Flood light car systems adapted for mining trucks and excavators.

Series	SlimⅢ Pro
Power	80W,100W,120W,150W,200W
Expected Life	Over 50,000 hrs
Rating	IP66
Color Rendering Index (CRI)	>70
Operating Temp	-30°C – +65°C
Relative Humidity	0-90% RH
Power Factor	>95%
Input Line Voltage	120-277/277-480 VAC
Input Line Frequency	50/60 Hz
LED Chips	Osram
DIMMING	0-10V Optional
LED Efficiency	3000K-140 lm/w、4000K-150 lm/w、5000K-150 lm/w、5700K-150 lm/w
Warranty	5-Year
Housing	Die Cast Aluminum A380 Alloy ADC12
Gasketing	Neoprene Rubber
Finish	Protective UV Stabilized Powdercoat 4000 Hour Salt Spray Tested to ASTM B117
Application	Heavy Industries, Manufacturing Plants, Smelting Zones,Stadium,Plaza,Mine field,Billboard

high temp LED flood lights optics

high temp LED flood lights size

Content not available

What features should high intensity led lights contain?

Generally, it needs to include high brightness/high luminous flux, wide lighting coverage, high temperature resistance, high-quality heat dissipation, long life, and flexible installation.SlimⅢPro fully meets these characteristics to meet varying project needs.

What is High Temp LED Industrial Flood Light?

Professional High Temp Industrial Flood Lights are designed to operate stably in ambient temperatures exceeding 60°C without reducing brightness and life. High-strength heat-resistant materials and excellent heat dissipation structures should be used, with a wide beam angle to ensure lighting quality in harsh industrial environments.

Can your flood lights only be used in high temperature industrial environments?

Although SlimⅢPro is designed for harsh industrial environments, it is also commonly used in other areas with high temperatures and requiring large-scale lighting, such as outdoor LED parking lot lights, stadiums, billboards, etc.

Types of Flood Lights and Their Special Functions

Type	Industrial Use Case
LED Flood Lights	Low energy, high efficiency, extreme temperature use
Flood Bulbs	Modular lighting in hazardous zones
Flood Lamps	Legacy systems, halogen, less heat-tolerant
Outdoor Flood Lights	Exterior machinery, open pit, mining sites
Underwater Light Projector	Cooling tanks, water treatment units
