Smart Led Street Lighting – High Protection

MoonⅡ led street lamp are designed to achieve optimal uniformity and maximize the distance between lamp poles. They use high-precision optical components and perfectly combine efficiency and functionality.100 and 50 watt led street light is suitable for city street lighting. The structure is made of die-cast aluminum, and the curved heat sink accelerates airflow and improves heat dissipation performance. It also has a high level of waterproof and anti-corrosion protection, efficient intelligent dimming, and a light efficiency of 150lm/W, it also performs very well in highway lighting.

Product Features

  1. Power 50W,70W,100W,120W,150W,200W,240W
  2. Operating temp   -30℃ to + 55 ℃
  3. A variety of lenses, angles and sizes available
  4. Efficient intelligent dimming





Request Our Latest Price

🔔 Ledrhythm products are designed for the global market. Please contact our sales team for certification details.

🔔 Products information is for reference only. Some options may not be available for each configuration. Please contact us for further details.

This led street lights can be equipped with various angle lenses, making road lighting more scientific, more standardized and more energy-saving.

Adjustable angle mounting bracket, adjustable and operable, more convenient on-site assembly, fully consider the customer’s experience.

Its design has excellent heat dissipation capabilities. It can be used normally even in hot summer, bringing a good lighting experience.

Within the rated range of use, the long service life can reduce the safety risks brought by product replacement, and can also reduce unnecessary additional costs.

Manufactured entirely from an injection molded aluminum foundry and features a seaside paint finish for optimized thermal management; Slim design has excellent wind grip; Multiple power functions; “LEDRHYTHM” logo embossed on the body of the luminaire;

  • Structure and materials
    Body: die-cast aluminum alloy, copper content less than 1%
    Seal: Polyurethane mechanical seal (EPDM IP66 rubber seal optional)
  • Optical module
    1.Glass: Ultra-clear flat tempered glass
    -LED Type: High Power-Thermal protection: NTC thermistor-Junction temperature s°85C
    2.Lens
    -Type:PMMAPC
    -Photometric distribution:
    Acrylic resin symmetrical/asymmetrical light distribution according to different applications
  • Electric block:
    LED driver
    Supply current: Programmable up to 1050 mA-Intensity variations: Level 1 to 5 autonomousThe driver can be integrated into public lighting remote managementsystems using the DALl 2.0 protocol and is D4l certified
Series MoonⅡ
Power 50W, 70W, 100W, 120W, 150W, 200W, 240W
Expected Life Over 50,000 hrs
Rating IP66
Color Rendering Index (CRI) >70
Operating Temp -30°C – +45°C
Relative Humidity 0-90% RH
Power Factor ≥95%
Input Line Voltage 120-277/277-480 VAC
Input Line Frequency 50/60 Hz
LED Chips Lumileds
DIMMING 0-10V Optional
LED Efficiency 3000K-140 lm/w、4000K-150 lm/w、5000K-150 lm/w、5700K-150 lm/w
Warranty 5-Year
Housing Die Cast Aluminum A380 Alloy ADC12
Gasketing Neoprene Rubber
Finish Protective UV Stabilized Powdercoat 4000 Hour Salt Spray Tested to ASTM B117
Application Road、Street、Highway

MoonⅡ-optics

100 watt led street light

  • Download IES File

light street lamp
street lamp application
led street bulb​ application
What is the lifespan of your LED street lights?
Our LED street lights are designed to operate stably and for long periods of time without maintenance, with a rated service life of 50,000 to 100,000 hours. They use well-known brand LED chips, are made of high-strength aluminum, and have excellent heat dissipation capabilities, ensuring consistent lighting effects for many years.
How much energy consumption does your street lamp reduce?
Our lamps have a light efficacy of up to 150lm/W, which significantly reduces power consumption compared to traditional high-pressure sodium lamps or metal halide lamps. In modern cities, the use of smart dimming and intelligent control functions can further reduce energy costs by up to 60%.
Can street light withstand harsh environments?
Yes. Our street lights are tested in high and low temperatures from -40°C to +50°C. With their anti-corrosion and high protection grade housing, they are completely waterproof, dustproof, anti-corrosion and shockproof. They can operate stably even in snowy, rainy or coastal areas.
